Product name

600W Cable Basket

Description

Designed for 600mm (W) racks, Modular fibre raceway, fire rated and Zero-U space-saving integration for 1U 19" rack mounting patch panels and 19" cable fall mounting

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 1.710 kg

PDF Specification Data Sheets

PH-CR-001 600w Cable Basket.pdf

PDF - 104.7KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

800W Cable Basket

Description

Designed for 800mm (W) racks, Modular fibre raceway, fire rated, Zero-U space-saving integration for 1U 19" rack mounting patch panels and cable fall mounting options

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 2.301 kg

PDF Specification Data Sheets

PH-CR-002 800w Cable Basket.pdf

PDF - 127.1KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Universal 90 Degree Bend

Description

Horizontal Right-Angle creates a 90° horizontal turn from a straight horizontal run.

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 2.301 kg

PDF Specification Data Sheets

PH-CR-013 Cable Swept Bend Weld Assy.pdf

PDF - 111KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Basket Angled End Cap

Description

Provides a tidy seal to the ends of fibre raceway

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 0.485 kg

PDF Specification Data Sheets

PH-CR-003 Cable Basket Angled End Cap.pdf

PDF - 67.5KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Joining Strap Angled

Description

Designed to quickly join two sections of fibre raceway

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 0.233 kg

PDF Specification Data Sheets

PH-CR-004 Joining Strap Angled.pdf

PDF - 70.1KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Fall

Description

Is used to exit the cable raceway and limit the bend radius of the cable

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 0.233 kg

PDF Specification Data Sheets

PH-CR-005 Cable Fall.pdf

PDF - 60.4KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cutout Blank

Description

Keeping fibre raceway neat and presentable by blanking off unused Cable falls

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 0.079 kg

PDF Specification Data Sheets

PH-CR-006 Cutout Blank.pdf

PDF - 46KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Basket Blanking Panel

Description

Keping fibre raceway neat and presentable by blanking off unused 1" U-space

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 0.198 kg

PDF Specification Data Sheets

PH-CR-007 Cable Basket Blanking Panel.pdf

PDF - 54KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

1u 19in
Cable Fall

Description

Is used for higher Qty's of cable or support cable plugged into 19in patch panel And limit the bend radius of the cable

Product Icon

Product Info

Material - Mild Steel
Thickness - 1.2mm v8
Weight - 0.733 kg

PDF Specification Data Sheets

PH-CR-008 1u 19in Cable Fall.pdf

PDF - 87.3KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support Angled

Description

Modular for various Height of adjustments for fixing

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.208 kg

PDF Specification Data Sheets

PH-CR-010 Cable Raceway Support Angled.pdf

PDF - 62.5KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support 50h

Description

Modular for various Height of adjustments for fixing

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.141 kg

PDF Specification Data Sheets

PH-CR-011 Cable Raceway Support 50h.pdf

PDF - 56.5KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support 100h

Description

Modular for various Height of adjustments for fixing

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.169 kg

PDF Specification Data Sheets

PH-CR-012 Cable Raceway Support 100h.pdf

PDF - 59.5KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support 150h

Description

Modular for various Height of adjustments for fixing

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.206 kg

PDF Specification Data Sheets

PH-CR-013 Cable Raceway Support 150h.pdf

PDF - 59.1KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support 200h

Description

Modular for various Height of adjustments for fixing

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.245 kg

PDF Specification Data Sheets

PH-CR-014 Cable Raceway Support 200h

PDF - 59.1KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support 250h

Description

Modular for various Height of adjustments for fixing

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.245 kg

PDF Specification Data Sheets

PH-CR-015 Cable Raceway Support 250h.pdf

PDF - 59.3KB

PDF Installation Sheets

n/a

PDF - 0KB

Product name

Cable Raceway Support Angle

Description

n/a

Product Icon

Product Info

Material - Mild Steel
Thickness - 2.0mm v12
Weight - 0.126 kg

PDF Specification Data Sheets

PH-CR-016 Cable Raceway Support Angle.pdf

PDF - 34KB

PDF Installation Sheets

n/a

PDF - 0KB
